Coolgear RS232 to TTL CMOS Serial Converter | DB9 Male to Female Compact Port-Powered Adapter for Embedded Systems, Microprocessors & Sensors | Plug & Play

Description

RS232 to TTL CMOS Conversion Conveniently convert to TTL from RS232 with this RS232 to TTL CMOS conversion adapter, it supports standard RS232 signals and does not require any additional power source once connected. Provides one RS232 to TTL/CMOS adaption Supports 5V and 3.3V Tolerance Signals Very compact Supports baud rate up to 115.2 Kbps Description RS232 to TTL Converter for PC and Workstation The RS232 to TTL converter can be used in CMOS conversion also for RS232 interface with TTL or CMOS voltage level. This TTL/CMOS converter is designed for PC, Workstation, thin client, or server providing instant conversion to devices needing a RS232 interface. Connect the RS232 TTL converter directly to your PC’s female DB-9 COM port, supports standard RS232 signals TxD, RxD, RTS, CTS, and GND. The converter does not require DC power from an outside source, it is powered by the RS232 signal. RS232 to TTL / CMOS Converter Features Provides one RS232 to TTL/CMOS adaption Supports 4-signal RS232 Conversion: (TxD, RxD, RTS, CTS, and GND) Supports DB-9 Female (DCE) to DB9 Male (TTL/CMOS) Connector Conversion Supports 5V and 3.3V Tolerance Signals Signal levels are inverted by the converter similar to standard RS232 but in TTL/CMOS swing level Supports baud rate up to 115.2 Kbps Port-Powered, no external power required No driver required fo all operating systems. Package Contents 1x RS232 to TTL / CMOS converter User Manual OS Support: Windows 10, Windows 8, Windows 7, Vista, and Windows XP Linux and Mac OS 10.X Specifications Product Specifications Identifier UPC 045079158368 Software OS Support Linux, Mac OSX, Win 10, Win 7, Win 8, Win Vista, Win XP Serial Attributes Serial Standards RS232 Serial Ports 1 USB Screw Lock Compatible Yes Mechanical Ports 1 Serial Port Weight .143 lbs Dimensions 6.750 × 5.125 × 1.00 in UPC: 045079158368
